1) 375 / 480 / 570 mm
2) See diagram
In accordance with VDI Guideline 2198 this specification sheet provides details of the standard truck only. Non-standard tyres, different masts, optional equipment, etc. may
result in different values.
Technical data in line with VDI 2198
Issue: 11/2009
Identifica
tion
1.1 Manufacturer (short form) Jungheinrich
1.2 Model EZS 6250
1.3 Drive Electrics
1.4 Manual, pedestrian, stand-on, seated, order picker operation seat
1.5 Load capacity/rated load Q t 25
1.7 Rated tractive power F N 5000
1.9 Wheelbase y mm 1540
W
eights
2.1.1 Net weight incl. battery (see row 6.5) kg 4250
2.3 Axle load, w.o. load, front / rear kg 1925 / 2325
Wheels / chassis
3.1 Tyres Lu, SE
3.2 Tyre size, at front mm 6.50-10
3.3 Tyre size, at rear mm 7.00-12
3.5 Wheels, number front/rear (× = driven wheels) 2 / 2x
3.6 Track width, front b
10
mm 1140
3.7 Track width, rear b
11
mm 1140
Basic dimensions
4.2.1 Total height h15 mm
4.7 Height of overhead guard h
6
mm 1900
4.8 Seat height/stand height h
7
mm 790
4.12 Coupling height h
10
mm 375 1)
4.16 loading area length l
3
mm 1400
4.18 loading area width b
9
mm 850
4.19 Overall length l
1
mm 3180
4.21 Total width b
1
/b
2
mm 1330
4.32 Floor clearance centre wheelbase m
2
mm 150
4.35 Turning radius W
a
mm 3150
4.36 Smallest pivot point distance b
13
mm 590
Performance
da
ta
5.1 Travel speed, w. / w.o. load km/h 10 / 26
5.5 Drawbar pull w. / w.o. load N 5000
5.6 Max. drawbar pull, laden/unladen N 18000
5.7 Gradeability laden/unladen % - / - 2)
5.8 Max. gradeability, laden/unladen % - / - 2)
5.10 Service brake hydraulic
Elec
-
trics
6.1 Drive motor rating S2 60 min. kW 23.0
6.4 Battery voltage/nominal capacity K5 V/Ah 80 / 620
6.5 Battery weight kg 1558
Misc.
8.1 Type of drive control AC
8.5 Trailer coupling, model/type DIN Stufenkupplung
8.6 Steering hydraulic
