1) 240 / 330 / 420 mm
2) See diagram
In accordance with VDI Guideline 2198 this specification sheet provides details of the standard truck only. Non-standard tyres, different masts, optional equipment, etc. may
result in different values.
Technical data in line with VDI 2198
Issue: 08/2010
Identifica
tion
1.1 Manufacturer (short form) Jungheinrich
1.2 Model EZS 570
1.3 Drive Electrics
1.4 Manual, pedestrian, stand-on, seated, order picker operation seat
1.5 Load capacity/rated load Q t 7
1.7 Rated tractive power F N 1400
1.9 Wheelbase y mm 1035
W
eights
2.1 Service weight kg 1220
2.3 Axle load, w.o. load, front / rear kg 570 / 650
Wheels / chassis
3.1 Tyres CSE
3.2 Tyre size, at front mm 4.00-8/6 PR
3.3 Tyre size, at rear mm 4.00-8/6 PR
3.5 Wheels, number front/rear (× = driven wheels) 1/2x
3.6 Track width, front b
10
mm 0
3.7 Track width, rear b
11
mm 860
Basic dimensions
4.7 Height of overhead guard h
6
mm 2120
4.8 Seat height/stand height h
7
mm 1030
4.12 Coupling height h
10
mm 240 1)
4.13 loading height without load h
11
mm 630
4.16 loading area length l
3
mm 400
4.17 overhang length l
5
mm 387
4.18 loading area width b
9
mm 795
4.19 Overall length l
1
mm 1820
4.21 Total width b
1
/b
2
mm 996
4.32 Floor clearance centre wheelbase m
2
mm 138
4.35 Turning radius W
a
mm 1650
4.36 Smallest pivot point distance b
13
mm 105
Performance
da
ta
5.1 Travel speed, w. / w.o. load km/h 8.5 / 18
5.5 Drawbar pull w. / w.o. load N 1400
5.6 Max. drawbar pull, laden/unladen N 5500
5.7 Gradeability laden/unladen % - / - 2)
5.8 Max. gradeability, laden/unladen % - / - 2)
5.10 Service brake hydraulic/mechanical
Electrics
6.1 Drive motor rating S2 60 min. kW 4.3
6.4 Battery voltage/nominal capacity K5 V/Ah 48 / 375
6.5 Battery weight kg 575
6.6 Energy consumption according to VDI cycle kWh/h 1.93
Misc.
8.1 Type of drive control Impuls/AC
8.4 Sound pressure level at operator’s ear according to EN 12053 dB (A) 57
