1) JetPilot height
2) Other coupling heights available
3) Rated tractive power
4) See diagram
5) Total length without coupling, as different coupling systems are available
In accordance with VDI Guideline 2198 this specification sheet provides details of the standard truck only. Non-standard tyres, different masts, optional equipment, etc. may
result in different values.
Technical data in line with VDI 2198
Issue: 06/2010
Identifica
tion
1.1 Manufacturer (short form) Jungheinrich
1.2 Model EZS 130
1.3 Drive Electrics
1.4 Manual, pedestrian, stand-on, seated, order picker operation stand-on
1.5 Load capacity/rated load Q t 3
1.7 Rated tractive power F N 600
1.9 Wheelbase y mm 930
W
eights
2.1.1 Net weight incl. battery (see row 6.5) kg 560
2.3 Axle load, w.o. load, front / rear kg 330 / 230
Wheels /
chassis
3.1 Tyres Vulkollan, Superelastik
3.2 Tyre size, at front mm Ø 230 x 78
3.3 Tyre size, at rear mm Ø 250 x 80
3.5 Wheels, number front/rear (× = driven wheels) 1x/2
3.7 Track width, rear b
11
mm 485
Basic dimensions
4.2.1 Total height h15 mm
4.8.1 Standing height h
7
mm 115
4.9 Height of tiller in drive position min. / max. h
14
mm 1400 1)
4.12 Coupling height h
10
mm 158 2)
4.19 Overall length l
1
mm 1275 5)
4.21 Total width b
1
/b
2
mm 600
4.32 Floor clearance centre wheelbase m
2
mm 50
4.35 Turning radius W
a
mm 1080
Perform
-
ance da
ta 5.1 Travel speed, w. / w.o. load km/h 9 / 10.5 4)
5.5 Drawbar pull w. / w.o. load N 600 3)
5.6 Max. drawbar pull, laden/unladen N 2000 4)
5.10 Service brake electro-magnetic
Electrics
6.1 Drive motor rating S2 60 min. kW 2.8
6.4 Battery voltage/nominal capacity K5 V/Ah 24 / 250
6.5 Battery weight kg 220
6.6 Energy consumption according to VDI cycle kWh/h 0.41
Misc.
8.1 Type of drive control AC SpeedControl
8.4 Sound pressure level at operator’s ear according to EN 12053 dB (A) 65
