1) With single plug-in coupling
In accordance with VDI Guideline 2198 this specification sheet provides details of the standard truck only. Non-standard tyres, different masts, optional equipment, etc. may
result in different values.
Technical data in line with VDI 2198
Issue: 09/2009
Identifica
tion
1.1 Manufacturer (short form) Jungheinrich
1.2 Model EZS 010
1.3 Drive Electrics
1.4 Manual, pedestrian, stand-on, seated, order picker operation pedestrian
1.5 Load capacity/rated load Q t 1
1.7 Rated tractive power F N 200
1.9 Wheelbase y mm 415
W
eights
2.1.1 Net weight incl. battery (see row 6.5) kg 190
2.3 Axle load, w.o. load, front / rear kg 85 / 105
Wheels / chassis
3.1 Tyres Vulkollan, Vollgummi
3.2 Tyre size, at front mm Ø 100 x 40
3.3 Tyre size, at rear mm Ø 230 x 70
3.5 Wheels, number front/rear (× = driven wheels) 2 / 1x
3.6 Track width, front b
10
mm 315
3.7 Track width, rear b
11
mm 370
Basic dimensions
4.2.1 Total height h15 mm
4.9 Height of tiller in drive position min. / max. h
14
mm 1270
4.12 Coupling height h
10
mm 150 1)
4.19 Overall length l
1
mm 700
4.21 Total width b
1
/b
2
mm 480
4.32 Floor clearance centre wheelbase m
2
mm 35
4.35 Turning radius W
a
mm 570
Perform
-
ance da
ta 5.1 Travel speed, w. / w.o. load km/h 5.4 / 6
5.5 Drawbar pull w. / w.o. load N 200
5.6 Max. drawbar pull, laden/unladen N 600
5.10 Service brake electro-magnetic
Elec
-
trics
6.1 Drive motor rating S2 60 min. kW 1.0
6.4 Battery voltage/nominal capacity K5 V/Ah 24 / 63
6.5 Battery weight kg 46
Misc.
8.1 Type of drive control 3-phase AC technology
