Technical data in line with vdi 2198 – Jungheinrich UPC User Manual
Page 3
Identification
1.1
Manufacturer (abbreviation)
Jungheinrich
Jungheinrich
Jungheinrich
Jungheinrich
1.1
1.2
Manufacturer’s type designation
UPC P1
UPC P2
UPC P5
UPC P6
1.2
1.3
Drive
electric
electric
electric
electric
1.3
1.4
Operator type
hand
1
)
hand
1
)
hand
1
)
hand
1
)
1.4
1.5
Load capacity / rated load
Q (t)
1.5
1.5
1.5
1.5
1.5
1.6
Load centre distance
c (mm)
400
500
500
2
)
570
1.6
1.9
Wheelbase
y (mm)
667
845
845
984
1.9
Weights
2.1
Service weight incl. battery (see line 6.5)
kg
190
212
212
225
2.1
2.2
Axle loading, laden front / rear
kg
845 / 845
856 / 856
856 / 856
863 / 863
2.2
2.3
Axle loading, unladen front / rear
kg
95 / 95
106 / 106
106 / 106
113 / 113
2.3
Wheels, Chassis
3.1
Tyres
Polyurethan
Polyurethan
Polyurethan
Polyurethan
3.1
3.2
Tyre size, front
mm
л 100 x 40
л 100 x 40
л 100 x 40
л 100 x 40
3.2
3.3
Tyre size, rear
mm
л 100 x 40
л 100 x 40
л 100 x 40
л 100 x 40
3.3
3.5
Wheels, number front rear (x = driven wheels)
2x / 2x
2x / 2x
2x / 2x
2x / 2x
3.5
3.6
Track width, front
b
10
(mm)
952
952
952
842
3.6
3.7
Track width, rear
b
11
(mm)
952
952
952
842
3.7
Basic Dimensions
4.4
Lift h
3
(mm)
27
27
27
27
4.1
4.15
Height, lowered
h
13
(mm)
150
150
150
150
4.15
4.16
Length of loading surface
l
3
(mm)
800
1000
1000
1140
4.16
4.18
Width of loading surface
b
9
(mm)
1010
1010
1010
900
4.18
4.19
Overall length (without load)
l
1
(mm)
864
1064
1064
1204
4.19
4.21
Overall width
b
1
/ b
2
(mm)
880 / 1034
880 / 1034
880 / 1034
770 / 924
4.21
4.26
Distance between wheel arms / loading surfaces
b
4
(mm)
651
651
651
468
4.26
4.27
Width across guide rolls
b
6
(mm)
1038
1038
1038
928
4.27
4.42
Pallet width
b
12
(mm)
1200
1200
1200
1140
4.42
4.43
Pallet length
l
6
(mm)
800
1000
1000
2
)
1140
4.43
Performance Data
5.1
Travel speed, laden / unladen
km / h
3.4 / 3.8
3
)
3.4 / 3.8
3
)
3.4 / 3.8
3
)
3.4 / 3.8
3
)
5.1
5.2
Lift speed, laden / unladen
m / s
0.012 / 0.013
0.012 / 0.013
0.012 / 0.013
0.012 / 0.013
5.2
5.3
Lowering speed, laden / unladen
m / s
0.014 / 0.013
0.014 / 0.013
0.014 / 0.013
0.014 / 0.013
5.3
E-Motor
6.1
Drive motor rating S
2
60 min
kW
0.23
0.23
0.23
0.23
6.1
6.2
Lift motor rating at S
3
15%
kW
2 x 0.15
2 x 0.15
2 x 0.15
2 x 0.15
6.2
6.4
Battery voltage, nominal capacity K
5
V / Ah
2 x 12 / 58
2 x 12 / 58
2 x 12 / 58
2 x 12 / 58
6.4
6.5
Battery weight
kg
46
46
46
46
6.5
Others
8.1
Type of drive control
impulse
impulse
impulse
impulse
8.1
8.4
Sound level at the driver‘s ear according to EN 12 053
dB (A)
62
62
62
62
8.4
1) Rail guided in pallet channel
2) Type P5 switchable, Euro pallet: c = 400 mm, l
6
= 800 mm
3) Travel speed with load with Q = 1000 kg
This specification sheet according to VDI regulation 2198 only provides technical values for the standard truck. Non-standard tyres, different masts, additional equipment, etc. could produce
other values. Right reserved for technical changes and improvements.
Technical data in line with VDI 2198
as at: 07/2010
