EFX 410/413
Standard values for working aisle widths (mm)
with rail guidance
Pallet size Stacking
depth
AST* Ast
3
/VDI
theoretical
AST
3
** prac-
tical
1200 x 800 1200 1740 3187 +500
1200 x 1200 1200 1740 3486 +500
800 x 1200 800 1390 3401 +500
with wire guidance
Pallet size Stacking
depth
Ast Ast
3
/VDI
theoretical
AST
3
** prac-
tical
1200 x 800 1200 1810 3187 +1000
1200 x 1200 1200 1810 3486 +1000
800 x 1200 800 1460 3401 +1000
* to h
3
= 4000 mm / for + 20 for h
3
> 4000 – 6000 mm /+ 70 mm for h
3
> 6000 mm
** The practical intersecting aisle width is a guide value.
s m2
m1
Wa
a/2
h 2
h 3
h 4
h 7
h 6
h 1
y
l 8
l 1
x l 3
b 1
b 2
b 8
b 3
b 12
l 6
b 7
Ast
e
b 5
Ast 3
r
b 6
z
b 14
c
Q
l
l 2
Standard mast types EFX 410/413
Lift
h
3
Lowered mast height
h
1
Free lift
h
2
Extended mast height
h
4
(mm) (mm) (mm) (mm)
Duplex ZT 3000 1) 2305 66 3772
3250 2430 66 4022
3500 2555 66 4272
3750 2680 66 4522
4000 2805 66 4772
4250 2930 66 5022
4500 3055 66 5272
4750 3250 66 5592
5000 3375 66 5842
5250 3500 66 6092
5500 3625 66 6342
5750 3750 66 6592
6000 3875 66 6842
Triplex DZ 4000 1) 2100 1410 4690
4250 1) 2190 1500 4940
4500 1) 2280 1590 5190
4750 2370 1680 5440
5000 2460 1770 5690
5250 2550 1860 5940
5500 2640 1950 6190
5750 2730 2040 6440
6000 2820 2130 6690
6250 2910 2220 6940
6500 3000 2310 7190
6750 3090 2400 7440
7000 3180 2490 7690
1) Attention: Overhead guard height 2277 mm or 2370 mm with strobe light on overhead guard
