Specifications
General
Product Name In-LineLinc Dimmer
Brand INSTEON
Manufacturer Product Number 2475D, INSTEON In-LineLinc Dimmer
UPC 689076402743
Patent Number
Protected under U.S. and foreign patents (see
www.insteon.com)
Warranty Two years, limited
Operation
On-Levels 32 locally, increments of 1% with software
Ramp Rates 0.1 to 9 seconds, up to 9 minutes with software
LED Indicator Off when load is on and vice versa
Operation Modes INSTEON only, X10 only, INSTEON and X10 combo
Combo Mode Message Order INSTEON, INSTEON cleanup, X10
Multi-Way Circuit Support As a receiver that controls a load
Setup Memory Non-volatile EEPROM
INSTEON Features
INSTEON Address 1 hard-coded out of 16,777,216 possible
INSTEON Links 417
INSTEON Powerline Frequency 131.65 KHz
INSTEON Minimum Transmit Level 3.2 Vpp into 5 Ohms
INSTEON Minimum Receive Level 10 mV
INSTEON Messages Repeated Yes
Mechanical
Mounting
Mounts in single-ganged junction box or light fixture such as a
recessed can light
Wire Nuts
4 included
Wires
Line (black)
Load (red)
Neutral (white)
Ground (bare copper)
Dimensions 2.75" H x 1.75" W x 0.88" D
Weight 3.6 oz.
Operating Environment Indoors
Operating Temperature Range 32°F to 104°F
Operating Humidity Range Up to 85% relative humidity
Electrical
