After the sensor is attached, scan for the sensor. Refer to Install the sensor on page 8.
Install the sensor
There are two options to install the sensor:
• Connect the sensor while power to the controller is off. The controller will look for and install new
sensors when it is turned on.
• Connect the sensor while power to the controller is on. Use the Scan Devices command to install
the new sensor:
Option Description
sc200 controller Go to MENU>TEST/MAINT>SCAN DEVICE
sc100 controller Go to MENU>TEST/MAINT>SCAN SENSORS
sc1000 controller Go to MENU>SYSTEM SETUP>DEVICE MANAGEMENT>SCANNING FOR NEW
DEVICES
Refer to Connect the sensor in a non-hazardous location on page 7 for digital sensor connection.
Sensor installation options
The installation and accessory options available for the LDO sensor are supplied with installation
instructions in the hardware kit.
Figure 5 shows several installation options. To order installation
hardware, refer to Replacement parts and accessories on page 17.
Figure 5 Installation options
1 Rail mount 4 Chain mount
2 Float mount 5 Union mount
3 Air blast system mount
