Overview of configuration steps
Menu Code Choices
out1 Output 1
o1.
Select sensor type Standard (Type A) / Traces (Type B)
Select saturation / concentration % / mg/L, ppm
Select current range 0-20 mA / 4-20 mA
Enter current start xxxx
Enter current end xxxx
Time averaging filter xxxx sec
22 mA signal in the case of error ON / OFF
Signal response during HOLD Last / Fix
Enter fixed value xxx.x mA
out2 Output 2
o2. Select temperature unit °C / °F
Select temperature probe 22NTC / 30NTC
Select current range 0-20 mA / 4-20 mA
Enter current start xxx.x
Enter current end xxx.x
Time averaging filter xxxx sec
22 mA signal for temp error ON / OFF
Signal response during HOLD Last / Fix
Enter fixed value xxx.x mA
Corr Correction
Co. Enter polarization voltage 0675 mV / xxxx mV
Select pressure unit bar / kPa / PSi
Select process pressure correction x.xxx bar / 1.013 bar
Enter salinity correction xx.xx mg/L
CAL Calibration mode
CA. Select saturation / concentration SAt / Conc
Enter cal timer interval xxxx h
