background image

63

N/O

(N/O

N/C)

100 %

(10 ... 100 %)

With USP function selected, relays

1 and 2 are used for USP function

(see page 94)

USP must have been selected as

measured variable.

Select: Contact response relay 1

N/O: normally open contact

N/C: normally closed contact

Select using 4key.

Press enter to proceed.

Code Display

Action

Choices

U1

Enter delay. Select using 4 key,

edit number using 5key.

Press enter to proceed.

0000 sec

(xxxxx sec)

U2

N/O

(N/O

N/C)

For function of relay 2, see Pg 95.

Select contact response

N/O: normally open contact

N/C: normally closed contact

Select using 4key.

Press enter to proceed.

Enter delay. Select using 4 key,

edit number using 5key.

Press enter to proceed.

0000 sec

(xxxxx sec)

For function of relay 1, see Pg 95.

Enter reduced USP factor

10 ... 100%
