35
Section 5
Operation—si792(x) D
(4–20 mA/HART)
The following section describes how to navigate and operate the
si792(x) D transmitters.
5.1 Measure mode
In the measure mode the display shows the dissolved oxygen value
and the temperature. The status bar is shown above the measure mode
indicator.
•
To return to the measure mode from the configure menu, press
CONF
and then
ENTER
.
•
To return to the measure mode from the calibration menu, press
CAL
and then
ENTER
.
Note: The waiting time for the stabilization of the measured value is
approximately 20 seconds.
5.2 Configuration
Use the configuration mode to specify the sensor, range and other
parameters for the system as shown in
Table 8
.
1. Press CONF and enter 1200 to enter the configuration mode.
2. Use the arrow and enter keys to change the settings. All settings
and options are shown in
,
,
.
Table 8 Configuration menu
Code
Setting
Passcode
