Clear-Com HME DX200 - Manual (Page 5)

5
Changing Batteries
When a battery is becoming weak, a voice in
the earpiece will say “Change battery.” When
this happens, remove the battery from the
headset by carefully sliding the battery-
release latch shown in Figure 8. Pull up on
the end of the battery near the battery-release
latch and lift the battery out.
Recharging Batteries
Place a battery in one of the four charging ports as shown in Figure 9.
Battery charging time is approximately 2 hours.
When the battery is charging, the red CHARGING light next to it will be on.
When a battery is fully charged, the green READY light next to it will be on.
Fully charged batteries should not be left in charging ports.
Store fully charged batteries in the six storage ports on the battery charger.
Battery
charging
Charged
battery in
storage port
Figure 9. Battery charger
Figure 8. Battery removal
Battery-release
latch
