ENGLISH
10s.
Pedestrian ACT
< 10s. >
Pedestrian ACT
< 11s. >
Automatic Pedestrian Closing: waiting time of the (M2) second gate leaf when in the open position. Once this time interval has
elapsed, the gate automatically closes. The waiting time interval can go anywhere from 0” to 300”.
< A.C.T. >
10s.
A.C.T.
< 10s. >
A.C.T.
< 11s. >
7.8 Time setting menu
Automatic closing: to set the waiting time when gate is in the open position.
Once this time is elapsed, the gate closes automatically. The waiting time can be set to between 0” and 300”.
TIMING ADJ.
USERS
INFO
ENCODER R
Imp. Run n
TIMING ADJ.
USERS
INFO
ENCODER R
Imp. Run n
TIMING ADJ.
USERS
INFO
ENCODER R
Imp. Run n
TIMING ADJ.
USERS
INFO
ENCODER R
Imp. Run n
< Cycle Time >
90s.
Cycle Time
< 90s. >
< Op. Delay M1 >
2s
Op. Delay M1
< 2s >
M1 delayed opening: the waiting time of the (M1) first gate lead, unlike the (M2) second one, after each opening command. The
waiting time can be set to between 0” and 10”.
Cycle time: the working time of the motor during opening or closing phases is anywhere from 10” to 150”.
Cycle Time
< 91s. >
Op. Delay M1
< 3s >
