CAME BX-246 Kit - Manual (Page 19)

/.
AF card
- Keep the CH1 button on the electronic card pressed. The led fl ashes.
- Press the transmitter button you wish to memorise. The LED will stay on to show memorisation has been successful.
LED flashing
LED on
Memorisation
CH1
CH2 = Channel for
direct command an
accessory device
connected to B1-B2.
- Repeat the points 1 and 2 procedures “CH2” button associating this to another button on the transmitter.
CH2
T2
/.
/.
T1
CH1
CH1 = Channel for direct
command to a function
of the gearmotor’s card,
(“open only/”open-
close-invert” or ”open-
stop-close-stop”
vommand, depending on
the choice made on DIP
switches 2 and 3).
