A
1) Coordinate the direction of travel of geared motors “A” and “B”, by modifying the rotation of motor “B” (see p. 11 geared motor-
endstop connection)
2) Carry out the electrical connections
on the geared-motor “A” command
card as per paragraph 6.3 electrical
connections.
A B
8 Connecting two joined motors with a single command
A
A
B
A B
5) On the geared motor A’s command card, insert the AF radio card.
Activate the radio command, using the CH2 channel (see chapter 7).
After memorising the code, connect contacts B1 and B2 on contacts 2 and 7.
On both cards, select the type of command (see Dip-Switches 2 and 3).
3) On both cards, carry out the same settings and activate the same functions (Dip Switches)
• • • • •• • • • • • • •• • •
1 2 3 4
O N
5 6 7 8 9 1 0 1 2 3 4
O N • • • • •• • • • • • • •• • •
1 2 3 4
O N
5 6 7 8 9 1 0 1 2 3 4
O N
L N 10 11 1 2 3P 7 C1 C3 FC F FA B1 B2 + E D
4) Carry out the connections between the two command cards as per the fi gure.
Note: the (2-3P) partial opening button needs to be connected to the command card’s terminal board of the motor in question
(motor A for opening left-wards, and B for opening right-wards).
