4.1 Operator
4 Description
2.1 Intended use
1 Legend of symbols
This symbol tells you to read the section with particular care.
This symbol tells you that the sections concern safety issues.
This symbol tells you what to say to the end-users.
2 Intended use and application
The FROG operator was engineered to power residential and condominium swing gates.
The use of this product for purposes other than those described above and installation executed in a manner other
than as instructed in this technical manual are prohibited.
3 Reference Standards
“IMPORTANT INSTALLATION, SAFETY INSTRUCTIONS”
“CAUTION: IMPROPER INSTALLATION MAY CAUSE SERIOUS DAMAGE, FOLLOW ALL INSTALLATION INSTRUCTIONS CAREFULLY”
“THIS MANUAL IS ONLY FOR PROFESSIONAL OR QUALIFIED INSTALLERS”
2.2 Limits to use
This product is engineered and manufactured by CAME CANCELLI AUTOMATICI S.p.A. and complies with current safety regu-
lations. Guaranteed 24 months if not tampered with.
The operator is made up of a foundation box, a release assembly, a gearmotor and a transmission arm.
The foundation casing is made of 1.5 mm thick ABS plastic on the sides and of 4mm galvanised steel on the bottom plate. On the
inside is the release assembly with a customised, manual-release key and the gearmotor – made of a cast aluminium shell, inside
of which operates an irreversible, gear-ratio and, endless screw plus helical crown system. A transmission arm is connected to
the gearmotor.
4.2 Technical features
—#
—#
For its quality processes management CAME cancelli automatici is ISO 9001:2000 certified, and for its environmental mana-
gement it is ISO 14001 certified. CAME engineers and manufactures all of its products in Italy.
This product complies with the following standards: see declaration of conformity.
FROG-A 230V
Power supply: 230 A.C. 50/60Hz
Motor power supply: 230 A.C. 50/60Hz
Max draw.: 1,9 A
Power: 200W
Max Torque: 320N
Opening time (90°): 18 s
Gear ratio: 1/1152
Duty cycle: 30%
Protection rating: IP67
Motor’s thermo-protection: 150°C
Weight: 11 kg
Model FROG-AV FROG-A / FROG-AE
Max width of gate leaf (m) 1,3 3,5* 2.5* 2,0
Max weight gate leaf (kg) 300 400 600 800
Note: we suggest to provide an electric lock to be mounted on the gate leaf.
FROG-AV
Power supply: 230 A.C. 50/60Hz
Motor power supply: 230 A.C. 50/60Hz
Max draw.: 2,5 A
Power: 300W
Max Torque: 240N
Opening time (90°): 9 s
Gear ratio: 1/1152
Duty cycle: 30%
Protection rating: IP67
Motor’s thermo-protection: 150°C
Weight: 11 kg
FROG-AE
Power supply: 230 A.C. 50/60Hz
Motor power supply: 230 A.C. 50/60Hz
Max draw.: 1,9 A
Power: 200W
Max Torque: 320N
Opening time (90°): 18 s
Gear ratio: 1/1152
Duty cycle: 30%
Protection rating: IP67
Motor’s thermo-protection: 150°C
Weight: 11 kg
—#
—#
—#
—#
