Introduction: The PWS AED-1 Automatic Electric Drain Kit is designed to drain
the water distiller boiling tank of impurities automatically, so that you don’t have
to. Every time you distil water and your storage tank fills up, the water distiller
will shut off and the Automatic Electric Drain Option will open and drain the
boiling tank of all soluble impurities. The boiler will remain empty until the water
distiller restarts, then the drain valve will automatically close and let your water
distiller boiling tank refill with fresh water and begin the distillation cycle again.
Your Optional PWS AED-1 kit has been shipped in one box. The Diagram
below shows all of the parts that will be in the PWS AED-1 box.
PWS-AED-1 Box Components Diagram
PWS AED-1 Box Check Off List
Check
List
Part No.
(A)
097090
1- Instruction Sheet
(B)
080077
1- Valve Body
(C)
030017
1- ¾” MPT Close Nipple
(D)
080109
1- Roll Teflon Tape
(E)
500310
1- PWS AED Motor Assembly, W/Cord, 120V
500311
1- PWS AED Motor Assembly, W/Cord, 240V
(A) 1x
(B) 1x
(E) 1x
(C) 1x
(D) 1x
PWS AED-1 Automatic Electric Drain Kit
Installation
TOOLS REQUIRED:
(A) 12” Adjustable Wrench
(B) 10” Adjustable Wrench
(C) Slotted Screwdriver
(C)
(A)
1
2
" M
IN
.
(B)
1
0
" M
IN
.
