Powerhead Assembly (Designer)

For Service Assembly Numbers, See the Back of this Manual

Item No.

Quantity

Part No.

Description

1 ..................... 1 .......................40264 ..........................Backplate, SS/SVO, W-T-Screws

2 ..................... 1 ...........................................................3200, Timer 7 or 12 Day

3 ..................... 1 .......................11838 ..........................Power Cord

4 ..................... 1 .......................13547 ..........................Strain Relief

5 ..................... 1 .......................40400 ..........................Harness, Drive, Designer/Environmental

8 ..................... 2 .......................10231 ..........................Screw, Drive Mounting

9 ..................... 2 .......................10302 ..........................Insulator

10 ................... 2 .......................10218 ..........................Switch

11 ................... 1 .......................10909 ..........................Connecting Link Pin

12 ................... 1 .......................10250 ..........................Retaining Ring

13 ................... 1 .......................10621 ..........................Connecting Link

14 ................... 1 .......................12576 ..........................Drive Cam, STF (Black)

....................... 1 .......................12102 ..........................Drive Cam, RR (White)

15 ................... 2 .......................10338 ..........................Roll Pin

16 ................... 1 .......................13366 ..........................Drive Bearing

17 ................... 2 .......................14923 ..........................Screw, Switch Mounting

18 ................... 1 .......................41543* ........................Motor, Drive, 115V, 50/60Hz

.................................................42579** .......................Motor, Drive, 24VAC/VDC, 50/60Hz

.................................................41545* ........................Motor, Drive, 230V, 50/60Hz

20 ................... 1 .......................12777 ..........................Brine Valve Cam, STF (Black)

....................... 1 .......................10815 ..........................Brine Valve Cam, RR (White)

Not Shown:

....................... 2 .......................10300 ..........................Screw, Timer Mounting

....................... 1 .......................13741 ..........................Hole Plug

....................... 1 .......................17904 ..........................Hole Plug

....................... 2 .......................19367 ..........................Screw, Thumb

....................... 1 .......................15441 ..........................Meter Cable Guide Assy (Econominder Only)

....................... 1 .......................15495 ..........................Meter Cable,13.87” (Econominder Only)

....................... 1 .......................60232-110 ...................Cover, Designer, 1 Pc, Black

* Bracket is integrated into the motor.
** Bracket is integrated into motor. Picture may not refl ect component.
