3200 Timer Assembly
Item No. Quantity Part No. Description
1 ..................... 1 .......................13870 ..........................Housing, Timer, 3200
2 ..................... 1 .......................14265 ..........................Clip, Spring
3 ..................... 3 .......................14087 ..........................Insulator
4 ..................... 1 .......................10896 ..........................Switch, Micro
5 ..................... 1 .......................15320 ..........................Switch, Micro, Timer
6 ..................... 2 .......................11413 ..........................Screw, Pan Hd Mach, 4-40 x 1-1/8
7 ..................... 1 .......................13886 ..........................Knob, 3200
8 ..................... 5 .......................13296 ..........................Screw, Hex Wsh, 6-20 x 1/2
9 ..................... 1 .......................11999 ..........................Label, Button
10 ................... 1 .......................13018 ..........................Pinion, Idler
11 ................... 1 .......................13312 ..........................Spring, Idler Shaft
12 ................... 1 .......................13017 ..........................Gear, Idler
13 ................... 1 .......................13164 ..........................Gear, Drive
14 ................... 1 .......................13887 ..........................Plate, Motor Mounting
15 ................... 1 .......................18743-1 ......................Motor, 120V, 60Hz, 1/30 RPM, 5600
.................................................19659-1 ......................Motor, 24V, 60Hz, 1/30 RPM
16 ................... 2 .......................13278 ..........................Screw, Sltd Fillister Hd 6-32 x .156
17 ................... 1 .......................15424 ..........................Spring, Detent, Timer
18 ................... 1 .......................15066 ..........................Ball, 1/4”, Delrin
19 ................... 1 .......................15465 ..........................Label, Caution
20 ................... 1 .......................19210 ..........................Program Wheel Assy
21 ................... 1 .......................13911 ..........................Gear, Main Driver, Timer
22 ................... 17 .....................41754 ..........................Pin, Spring, 1/16 x 5/8 SS, Timer
23 ................... 1 .......................13011 ..........................Arm, Cycle Actuator
24 ................... 1 .......................13864 ..........................Ring, Skipper Wheel
25 ................... 2 .......................13311 ..........................Spring, Detent, Timer
26 ................... 2 .......................13300 ..........................Ball, 1/4”, SS
27 ................... 1 .......................14381 ..........................Skipper Wheel Assy, 12 Day
.................................................14860 ..........................Skipper Wheel Assy, 7 Day
28 ................... 1 .......................13014 ..........................Pointer, Regeneration
29 ................... 1 .......................40096-24 ....................Dial, 12 AM Regen Assy, Black
.................................................40096-02 ....................Dial, 2 AM Regen Assy, Black
30 ................... 1 .......................13881 ..........................Bracket, Hinger Timer
31 ................... 2 .......................11384 ..........................Screw, Phil, 6-32 x 1/4 Zinc
32 ................... 1 .......................13902 ..........................Harness, 3200
33 ................... 2 .......................40422 ..........................Nut, Wire, Tan
34 ................... 1 .......................15354-01 ....................Wire, Ground, 4”
35 ................... 1 .......................14007 ..........................Label, Time of Day
For Service Assembly Numbers, See the Back of this Manual
