Hydrotech 2510 Econominder Service Manual - Manual (Page 13)

Page 13
3210 Timer Assembly
For Service Assembly Numbers, See the Back of this Manual
Item No. Quantity Part No. Description
1 ..................... 1 .......................13870 ..........................Housing, Timer, 3200
2 ..................... 1 .......................13802 ..........................Gear, Cycle Actuator
3 ..................... 1 .......................40096-02 ....................Dial, 2 AM Regen Assy, Black
4 ..................... 1 .......................13886 ..........................Knob, 3200
5 ..................... 4 .......................13296 ..........................Screw, Hex Wsh, 6-20 x 1/2
6 ..................... 2 .......................11999 ..........................Label, Button
7 ..................... 1 .......................60405-15 ....................Program Wheel, w/34” Std Label, w/People Label Set @21
8 ..................... 1 .......................13806 ..........................Retainer, Program Wheel
9 ..................... 1 .......................13748 ..........................Screw, Flat Head St, 6-20 x 1/2
10 ................... 1 .......................14265 ..........................Clip, Spring
11 ................... 1 .......................15424 ..........................Spring, Detent, Timer
12 ................... 1 .......................15066 ..........................Ball, 1/4” Delrin
13 ................... 1 .......................13018 ..........................Pinion, Idler
14 ................... 1 .......................13312 ..........................Spring, Ilder Shaft
15 ................... 1 .......................13017 ..........................Gear, Idler
16 ................... 1 .......................13164 ..........................Gear, Drive
17 ................... 1 .......................13887 ..........................Plate, Motor Mounting
18 ................... 1 .......................18743-1 ......................Motor, 120V, 60Hz 1/30 RPM, 5600
19 ................... 1 .......................13278 ..........................Screw, Fillister Hd, 6-32 x .156
20 ................... 1 .......................13830 ..........................Pinion, Program Wheel Drive
21 ................... 1 .......................13831 ..........................Clutch, Drive Pinion
22 ................... 1 .......................14276 ..........................Spring, Meter, Clutch
23 ................... 1 .......................14253 ..........................Retainer, Clutch Spring
24 ................... 3 .......................11384 ..........................Screw, Phil, 6-32 x 1/4
25 ................... 1 .......................13881 ..........................Bracket, Hinge Timer
26 ................... 3 .......................14087 ..........................Insulator
27 ................... 1 .......................10896 ..........................Switch, Micro
28 ................... 1 .......................15320 ..........................Switch, Micro, Timer
29 ................... 2 .......................11413 ..........................Screw, Pan Hd Mach, 4-40 x 1-1/8
30 ................... 1 .......................14198 ..........................Label, Indicator
31 ................... 1 .......................15465 ..........................Label, Caution
32 ................... 1 .......................14007 ..........................Label, Time of Day
33 ................... 1 .......................14045 ..........................Label, Instruction
34 ................... 1 .......................13902 ..........................Harness, 3200
35 ................... 2 .......................40422 ..........................Nut, Wire, Tan
36 ................... 1 .......................15354-01 ....................Wire, Ground, 4”
37 ................... 1 .......................19210 ..........................Program Wheel Assy
38 ................... 17 .....................41754 ..........................Pin, Spring, 1/16 x 5/8 SS Timer
39 ................... 1 .......................13911 ..........................Gear, Main Drive, Timer
40 ................... 1 .......................15354-01 ....................Wire, Ground 4”
