Maintenance Instructions

Maintenance of your new water filter requires very little time or effort but it is essential. Regular maintenance will ensure many years of
efficient and trouble-free operation.

Care of All Water Filters

To retain the attractive appearance of your new water filter, clean occasionally with a mild soap solution. Do not use abrasive cleaners,
ammonia or solvents. Never subject your filter to freezing or to water temperatures above 120

o

F.

Replacing the Media Bed

NE - Neutralizing Filter - the media bed in a neutralizing filter is slowly dissolved and has to be replaced. The frequency of
replacement varies, depending on water quality - consult your dealer to determine the expected life of your media bed.

AC - Taste and Odor Filter - under normal operating conditions the effective life of the filter media is approximately one to three years,
depending on the water quality, after which, taste and odor problems may return. When this happens, contact your dealer for a
replacement media bed.

MM - Sediment and Turbidity Filter - under normal operating conditions, the media should never need to be replaced. However, if
you experience pressure loss and cannot correct it with a manual regeneration, your media bed may need replacing - contact your
dealer.

Installation & Replacement Filter Media Pak

Check to ensure all media parts are received.

The first step in replacing the media bed is to shut off the water supply to the filter. Then place the unit into the backwash position to
release any pressure in the lines. At this point, you must disconnect the plumbing from the inlet and outlet. Then unscrew the control
valve from the fiberglass tank. Once this has been done, remove the distributor tube. Then you can remove the filter media and two
types of gravel from the tank. The quickest way to do this is by simply tipping the tank upside down into a large drum or pail. The tank
must be rinsed out completely and have no media or gravel left in it at all.

Loading the Media Pak

Place the distributor tube back down the center of the tank. NOTE: the top of this tube should be
plugged with a rag or cork to prevent media from entering. Pour the bag of coarse gravel into
the tank, then pour the bag of fine gravel into the tank.

It is important that the distributor tube is not moved or pulled out as it is not possible to
put it down to the bottom of the tank once gravel or media are in the tank.

Finally pour the larger bag(s) of media into the tank in the following order:

Multimedia Filters

1. Coarse gravel (1/2 x 1/4)

4. Fine garnet (30 x 40)

2. Fine gravel (1/8 x 1/16)

5. Fine filter sand (.45 x .55)

3. Coarse gravel (8 x 12)

6. Anthrafilt

ACF Carbon Filters

Neutralizing Filters

1. Coarse gravel

1. Coarse gravel

2. Fine gravel

2. Fine gravel

3. Carbon

3. Calcite
4. Mag Oxide

Once this is done, the rag or cork should be removed from the distributor tube. Clean off the top
of the tank. Finally place the control valve on the tank and on to the distributor tube. Tighten the
control valve on to the tank. Connect or reconnect the inlet and outlet and drain. The control
valve should be in the backwash position. Slowly open the inlet valve water supply and slowly fill
the filter tank until water appears at the open drain line. Return the control to the service position
and shut the inlet off for approximately one hour to allow the media to soak in the water.

After one hour, turn inlet water on slowly and place the control into the backwash position and
plug the unit’s electrical cord into a constant power source. Let the unit continue through its
regeneration cycle automatically.

The regeneration is necessary so all media fines are backwashed down the drain to ensure
clean filtered water. After this media has been replaced, it may be necessary to reset the
present time of day on the control valve timer as it will have been unplugged for some time.

7

Control
Valve

Drain
Line

Distributor
Tube

Media

Fine
Gravel

Coarse
Gravel
