20
2. Electrical Service Specifications
a. Gas and Steam Models Only
IMPORTANT: Figures shown are for non-reversing models only. For reversing models contact the
factory.
IMPORTANT: The dryer must be connected to the electric supply shown on the data label that is
affixed to the left side panel/wall area behind the control door. In the case of 208
VAC or 240 VAC, the supply voltage must match the electric service specifications
of the data label exactly.
IMPORTANT: The wire size must be properly sized to handle the related current.
WARNING: 208 VAC AND 240 VAC ARE NOT THE SAME. Any damage done to dryer
components due to improper voltage connections will automatically VOID THE
WARRANTY.
NOTE: ADC reserves the right to make changes in specifications at any time without notice or
obligation.
M LG-75 (G
AS
)
M LS-75 (S
TEAM
)
ELECTRICAL SERVICE SPECIFICATIONS (PER DRYER)
IMPORTANT: 208 VAC and 240 VAC ARE NOT THE SAME. When ordering, specify exact voltage.
NOTES:
A. Fuse ratings are dual element, time delay, current limiting, class RK1 or RK5 ONLY.
B. Circuit breakers are thermal/magnetic (industrial) motor curve type ONLY. For others, calculate/verify correct
breaker size according to appliance amp draw rating and type of breaker used.
C. Circuit breakers for 3-phase (3ø) dryers must be 3-pole type.
SERVICE
VOLTAGE
PHASE
WIRE
SERVICE
APPROX.
AMP DRAW
MINIMUM
WIRE SIZE
FUSING
CIRCUIT
BREAKER
Dual Element
Time Delay
120 (60 Hz)
1
ø
2
13
*
20
25
208 (60 Hz)
1
ø
2
7.6
*
12
15
208 (60 Hz)
3
ø
3/4
4.7
*
8
15
240 (50/60 Hz)
1ø
2
7
*
12
15
240 (50/60 Hz)
3ø
3/4
4.9
*
8
15
380-400 (50 Hz)
3
ø
3/4
3
*
5
15
416 (50 Hz)
3
ø
3/4
3.1
*
5
15
460 (60 Hz)
3
ø
3/4
2.8
*
5
15
* AWG Stranded Wire Type ... size wire as per National Electrical Code or local codes.
