Basic Installation/Operation

F232156

UW Models with S-Control

1. Turn on the main power source (circuit breaker or

cut-off switch on the wall).

2. Use left hand to press and hold the Door Unlock

button located on the lower right front of the
control panel. Refer to Figure 18.

Figure 18

3. Use right hand to turn door handle clockwise,

and swing the door left to open. Refer to
Figure 19.

Figure 19

4. Load the machine to full capacity whenever

possible. DO NOT OVERLOAD.

Figure 20

NOTE: When washing items which may
disintegrate or fragment, such as mop heads or
sponges, use laundry nets to prevent drain
blockage.

5. Close door and turn handle counterclockwise.

Door will lock automatically.

MD003J

MD004J

PHM590N

WARNING

MACHINE MAY BE HOT

AND CAUSE BURNS

ATTEMPT NO ENTRY UNTIL

BASKET HAS STOPPED

SERIOUS INJURY MAY RESULT

Be careful around the open door,
particularly when loading from a level below
the door. Impact with door edges can cause
personal injury.

SW025

CAUTION

Check the door safety interlock daily before
the machine is placed in operation.

SW024

CAUTION
