Basic Installation/Operation
25
F232156
UW 2 Speed Models with P-Control,
S-Control, Mechanical Timer or B-Control
Dimensional Clearances
Allow a minimum of 24 inches (60 cm) at the rear, and
18 inches (45 cm) at the sides for maintenance,
inspection and adjustment. Allow at least 18 inches
(45 cm) between machines in multiple installations.
Machine dimensions are indicated in Figure 6 and
specified in Table 9.
NOTE: The dimensions shown here are for
planning purposes only. They are approximate and
subject to normal manufacturing tolerances. If
exact dimensions are required for construction
purposes, contact the distributor or the
manufacturer. We reserve the right to make
changes at any time without notice.
Table 9
UW 2 Speed Machine Dimensions
(Refer to Figure 6)
Dimensions
35
60
in.
mm
in.
mm
A
30.13
765
35.63
905
B
*
32.5
826
36.63
930
C
23.75
603
28.25
718
D
38.25
972
45
1143
E
0.5
13
1
25
F
55.5
1410
64.5
1638
G
30.5
775
36
914
H
8
203
15.5
394
I
43.88
1114
55
1397
*
Overhang dimensions for the optional starch dispenser are as follows:
UW35, 3.88 inches (9.86 cm); UW60, 1.75 inches (4.45 cm).
