Do not inflate air springs over 50 psi – Hellwig Air 6110 User Manual
Page 4
559-734-7451 800-367-5480 FAX 559-734-7460
5
5. Attach frame adapter to air spring as shown with 3/8” x 3/4” flat head cap
screws. Install heat shields as shown to passenger side assembly before attaching
bracket. Torque bolts to 20 ft-lb.
Passenger Side
3/8” flat head cap screws
Install heat shields as
shown on passenger
side only.
6110( R-6110)
DO NOT INFLATE AIR SPRINGS OVER 50 PSI
01/24/2013
