Hellwig Air 6102 User Manual
Page 4
AIR SPRING
HEAT SHIELD CAN BE ROTATED FOR
BEST FIT TO PROTECT AIR SPRING FROM
VEHICLES EXHAUST
VEHICLE’S FRAME
FRAME BRACKET
AXLE BRACKET
SADDLE BRACKET
INNER FRAME BRACKETS VIEW OF FRONT & REAR BRACKETS
CUT END FACING EACH OTHER FOR AIR FITTING CLEARANCE
VEHICLES AXLE
NOTE PUNCHED HOLES ON FRAME BRACKET FOR RIVET
CLEARANCE ON VEHICLES FRAME
TOP AXLE BRACKET HAS DIFFERENT PUNCHED HOLE FOR BEST FIT
INNER FRAME
BRACKETS
AIR FITTING
