ASUS 802.11g WL-HDD2.5 73
5. Appendix
Specifications
LAN Ethernet port Support Ethernet and 802.3 with maximum bit rate 10/
100 Mbps and auto cross-over function
(MDI/MDI-X)
Connector 1 x RJ-45 for 10/100BaseT
Antenna Support 2 (One internal inverted-F PCB antenna and one
external dipole antenna)
Connector Reverse-SMA antenna connector
LED • Power x 1
• HDD access x 1
• Wireless activity x 1
• USB copy x 1
• LAN port x 2 (Ethernet Link/Activity with 10/100 Mbps)
USB USB 1.1
RTC Supports real time clock
Reset button Push for 5 seconds to restore factory settings.
Hard disk drive 2.5-inch slim attachable hard drive
IDE controller • Ultra DMA 100
• Conforms to ATA-5 specifications
DC power adapter • AC input: 100V~240V (50~60 Hz)
• DC output: 5V with maximum 2A current
Emissions CE mark, FCC Part 15
Size 180 mm x 90 mm x 25 mm
Weight 200g
Operating
frequency 2.4 - 2.5 GHz
Spreading OFDM and DSSS
Modulation OFDM, CCK, DQPSK, DBPSK
Data rate • 802.11g: 6, 9, 12, 18, 24, 26, 54 Mbps
• 802.11b: 1, 2, 5.5, 11 Mbps
