8
Description
Type 8071
Fig. 1: Running/displacement of oval rotors
The remote instrument converts the frequency into a flow rate by
using the correct K factor.
5.3. Description of the name plate
1
2
3
4
5
Model
Flow Range
Max Pressure
Max Temp
Serial No
Type 8071 Flow Sensor
433864N
2-100LPH
1000kPa/55Bar
120°C
D34128
Fig. 2: Name plate of the device
1. Order code of the device
2. Flow rate measuring range
3. Max. pressure
4. Max. temperature
5. Serial number
English
