Start-up
8
START-UP
8.1
Safety instructions
WARNING!
Risk of injury from improper operation!
Improper operation may result in injuries as well as damage to the
device and the area around it.
▶ Before start-up, ensure that the operating personnel are familiar
with and completely understand the contents of the operating
instructions.
▶ The safety instructions and “2 Authorized use” must be
observed.
▶ Only adequately trained personnel may start up the equipment/
device.
8.2
Control diagram
T0
T5
T4
T3
T2
T1
T6
V1
V2
V3
T1
Fig. 5: Control diagram
V1 = inlet valve
V2 = dosing valve
V3 = discharge valve
The optional control times are saved in the dosing unit software and
cannot be changed.
