1-4
Installation and Operation Manual
X-VA-1110-1140-eng
Part Number: 541B040AAG
September, 2012
Brooks ® 1110 and 1140 Series
Section 1 Introduction
Housing and Window Bezel
Standard: Aluminum with polyurethane paint.
Optional: 18-8 stainless steel.
End Fittings
316 stainless steel,steel, Hastelloy C, CPVC Sizes 2-8,
PVC Sizes 9-10, brass.
(Brass, Hastelloy C, CPVC/PVC fittings not available with flanged
connection).
Window
Scratch resistant, UV stabilized polycarbonate.
Protective sleeve must remain over glass tube.
(Meter sizes 7 - 13 only)
Fasten meter windows securely.
Failure to comply could result in serious personal
injury or property damage.
WARNING
GLASS TUBE EXPLOSION HAZARD
Packing Material
Standard: Teflon
® , Neoprene ® , Viton ® fluoroelastomers.
O-rings
Standard: Teflon.
Optional: Buna, Viton
® fluoroelastomers.
Gland Rings
Standard: Steel, 18-8 stainless steel.
Gland Followers
Standard: Sizes 2-9 aluminum, Sizes 10-13 steel.
Optional: 18-8 stainless steel.
Side Plate Gaskets
Anchorite.
Bolts
18-8 stainless steel.
Connections (Refer to Table 1-2)
Standard:
150 lbs, 300 lbs RF flanges per ANSI B 16.5
NPT female connections.
Optional:
125/175 RA flange finish
Connection Orientation
Vertical or horizontal optional on inlets and outlets.
Connection rotatable 360° at 90° intervals.
Meter Dimensions
127mm to 250mm (Refer to Figure 1-1)
