Installation and Operation Manual
X-VA-MT3810-eng
Part Number: 541B050AAG
December, 2008
Model MT 3810
Section 1 Introduction
1-1
1-1 Description
The Brooks ® Model MT 3810 Variable Area Flowmeter is a rugged, all
metal flowmeter offering 5% full scale accuracy. The Model MT 3810 is
constructed with stainless steel components for measuring a variety of
liquid and gas applications.
Flow rate indication is provided by means of magnetic coupling where a
magnet, encapsulated in the float, is coupled to a rotatable magnet located
in the rear of the indicator, thus turning the dial indicator mounted on the
meter.
Optional accessories available include 4-20 mA output with HART ®
microprocessor transmitter with or without configurable alarms and pulse
output for totalization. The microprocessor electronics are based on the
proprietary Smart Meter Manager
TM technology utilized as the basis for an
array of Brooks products. Also available are front adjustable inductive
alarms.
1-2 Design Features
• Broad range of flow capacities
• 5% Full scale accuracy
• Versatile construction for all gas and liquid applications
• No back pressure required for operation
• Flanged or female NPT connections
• Optional 4-20 mA and HART programmable microprocessor transmitter
with or without alarms and pulse output for totalization
• Electronics designed with either intrinsically safe or explosion proof
construction to meet UL (US & Canada) ATEX certifications and CE
requirements
1-3 Specifications - Meter
Do not operate this instrument in excess of the specifications
listed below. Failure to heed this warning can result in serious
personal injury and/or damage to the equipment.
WARNING
Capacities, Pressure Drop and Viscosity Immunity Ceilings
Refer to Table 1-1
Accuracy
Standard Flow Accuracy: ± 5% Full Scale
Repeatability
0.25% Full Scale
Pressure Ratings
Refer to Table 1-2 for maximum non-shock pressure
Pressure Equipment Directive (PED) 97/23/EC
Flow meter complies under Sound Engineering
Practices (SEP) or Catagories I, II or III
