Model MT 3810
Section 3 Operation
The following are two examples of typical programming via a Emerson
Model 275 hand-held communicator.
Example 1: Programming Flow Rate Units.
From the Online Menu, select
Device Setup.
From the Device Setup Menu,
select
Detailed Setup.
From the Detailed Setup Menu,
select
Measurements.
F1 F4 F3 F2
SAVE
Brooks MT 38xxVA
On-line
5 LRV
1 Device Setup
2 PV
3 AO
4 URV
50.00 gpm
setup
25 gpm
12.0 mA
0.00 gpm
F1 F4 F3 F2
SAVE
Brooks MT 38xxVA
Device Setup
1 Process Variables
2 Diags & Services
3 Basic Setup
4 Detailed Setup
F1 F4 F3 F2
SAVE
Brooks MT 38xxVA
Detailed Setup
5 Device Info
1 Measurements
2 Computations
3 Outputs
4 Alarms
