1-10
Installation and Operation Manual
X-VA-MT3809G-MT3810G-eng
Part Number: 541B182AAG
September, 2013
Models MT3809G & MT3810G
Section 1 Introduction
NEPSI NEPSI NEPSI NEPSI NEPSI
IS: Ex ia IIC T6
Ambient Temperature: -40°C to 65°C
Enclosure: IP66/ IP67
XP: Ex d IIC T6
Ambient Temperature: -40°C to 65°C
Enclosure: IP66/ IP67
NI: Ex nA IIC T6
Ambient Temperature: -40°C to 65°C
Enclosure: IP66/ IP67
GOST GOST GOST GOST GOST-R -R -R -R -R
CCOE CCOE CCOE CCOE CCOE
KKKKKOSHA OSHA OSHA OSHA OSHA
Appr Appr Appr Appr Approvals P ovals P ovals P ovals P ovals Pending ending ending ending ending
AAAAATEX TEX TEX TEX TEX
IS: II 2 G Ex ia IIC T6 or
II 2 D Ex iaD 21 IP66/IP67 T70°C or
II 2 D Ex tD A21 IP66/IP67 T70°C
Ambient Temperature: -40°C to 65°C
Enclosure: IP66/ IP67
XP: II 2 G Ex d IIC T6
II 2 D Ex tD A21 T 85°C
Ambient Temperature: -40°C to 65°C
Enclosure: IP66/ IP67
NI: II 3 GD EEx nA IIC T6 T 70°C
Ambient Temperature: -40°C to 65°C
Enclosure: IP66/ IP67
Mechanical indicator only:
II2GD IIC
II3GD IIC
IECEX IECEX IECEX IECEX IECEX
IS: Ex ia IIC T6
Ambient Temperature: -40°C to 65°C
Enclosure: IP66/ IP67
XP : Ex d IIC T6
Ambient Temperature: -40°C to 65°C
Enclosure: IP66/ IP67
NI: Ex nA IIC T6
Ambient Temperature: -40°C to 65°C
Enclosure: IP66/ IP67
UL UL UL UL UL / CSA / CSA / CSA / CSA / CSA (North (North (North (North (North American American American American American Appr Appr Appr Appr Approvals) ovals) ovals) ovals) ovals)
IS: Class I, Groups A, B, C, D;
Class II, Groups E, F, G;
Class III; T6
Ex ia IIC T6
Ambient Temperature: -40°C to 65°C
Enclosure: Type 4X/ IP66/ IP67
Zone - IS
IS: Ex ia IIC T6
Ambient Temperature: -40°C to 65°C
Enclosure: IP66/ IP67
XP: Class I, Groups A, B, C, D;
Class II, Groups E, F, G;
Class III; T6
Class I, Zone 1 AEx d IIC T6
Ex d IIC T6
Ambient Temperature: -25°C to 65°C
Enclosure: Type 4X/ IP66/ IP67
Zone XP
XP : Ex d IIC T6
Ambient Temperature: -40°C to 65°C
Enclosure: IP66/ IP67
NI: Class I, Division 2, Groups A, B, C, D;
Class II, Groups E, G;
Class III; T6
Ex nA IIC T6
Ambient Temperature: -40°C to 65°C
Enclosure: Type 4X/ IP66/ 67
Zone - NI
NI: Ex nA IIC T6
Ambient Temperature: -40°C to 65°C
Enclosure: IP66/ IP67
