2-1

Models MT 3809 & 3819

Section 2 Installation

Installation and Operation Manual

X-VA-MT3809-3819
Part Number: 541B049AHG
September, 2008

2-1 General

This section contains the procedures for the receipt and installation of the
instrument. See Section 1 for dimensional and connection requirements.
Do not attempt to start the system until the instrument has been
permanently installed. It is important that the start-up procedures be
followed in the exact sequence presented.

2-2 Receipt of Equipment

When the instrument is received, the outside packing case should be
checked for damage incurred during shipment. If the packing case is
damaged, the local carrier should be notified at once regarding his liability.
A report should be submitted to your nearest Product Service Department.

Brooks Instrument
407 W. Vine Street
P.O. Box 903
Hatfield, PA 19440 USA
Toll Free (888) 554-FLOW (3569)
Tel (215) 362-3700
Fax (215) 362-3745
E-mail: [email protected]
www.BrooksInstrument.com

Brooks Instrument

Neonstraat 3

1-4-4 Kitasuna Koto-Ku

6718 WX Ede, Netherlands

Tokyo, 136-0073 Japan

P.O. Box 428

Tel 011-81-3-5633-7100

6710 BK Ede, Netherlands

Fax 011-81-3-5633-7101

Tel 31-318-549-300

Email: [email protected]

Fax 31-318-549-309
E-mail: [email protected]

Remove the envelope containing the packing list. Outside of your clean area,
carefully remove the equipment from the packing case. Make sure spare
parts are not discarded with the packing material. Inspect for damaged or
missing parts.

2-3 Recommended Storage Practice

If intermediate or long-term storage of equipment is required, it is
recommended that the equipment be stored in accordance with the
following:

a. Within the original shipping container.

b. In a sheltered area preferably a warm, dry heated warehouse.

c. Ambient temperature 21°C (70°F) nominal, 40°C (104°F) maximum

and 7°C (45°F) minimum.

d. Relative humidity 45% nominal, 60% maximum and 25% minimum.
