2-4
Installation
Brooks ® Models BM01 and BM02
Installation and Operation Manual
X-PD-BM01-02-eng
Part Number: 541B042AHG
March, 2008
Figures 2-2 Typical Installation for Fuel Metering
Horizontal Installation
Note: Rotor shafts are
parallel to the ground.
FLOW FLOW
INLET
F
L
O
W
F
L
O
W
INLET
Vertical Installation
Figure 2-1 Proper Orientation of Meter Assembly
Important Note: Rotor shafts must
always be parallel to the ground.
