6 of 14 MN301030 Rev B
COMPONENTS Step Five
DeltaSpan is offered in six different models, based upon pressure rating and material. Depending on the
model purchased, you may or may not have been shipped all the components shown below.
 DeltaSpan™ General Purpose External Mount Pressure Level Transmitter
Part
Number
Maximum
Pressure
Range in
Water Column
Interface/
Connection
LD30‐S001
LD30‐S011
05 psi 11.54 ft wc / 3.52 m wc
9’ (2.7 m) Cable
Terminal Block in Housing
LD30‐S201
LD30‐S211
15 psi 34.63 ft wc / 10.56 m wc
9’ (2.7 m) Cable
Terminal Block in Housing
LD30‐S401
LD30‐S411
30 psi 69.30 ft wc / 21.12 m wc
9’ (2.7 m) Cable
Terminal Block in Housing
 Quick Start Guide
