SPECIFICATIONS
Step Two
Service:
Compatible gases or liquids
Wetted Materials:
Body: 316 SS, 316L SS
Accuracy:
±0.25% of full scale
Temperature Limit:
F: 0° to 200°
C: ‐18° to 93°
Compensated Temperature Range:
F: 0° to 175°
C: ‐18° to 79°
Thermal Effect:
Less than ±0.02%/°F.
Pressure Limit:
‐S0_1: 10 psig (maximum) / 50 psig (over pressure)
‐S2_1: 30 psig (maximum) / 150 psig (over pressure)
‐S4_1: 60 psig (maximum) / 300 psig (over pressure)
Power Requirement:
13 to 30 VDC
Output Signal:
4 to 20 mA, 2‐wire
Response Time:
50 ms
Max. Loop Resistance:
1300 Ohms @ 30 VDC
Current consumption:
38 mA (maximum)
Electrical Connections:
‐S_01: Cable (9’ length)
‐S_11: Conduit Housing with Terminal Block
Process connection:
¼” male NPT
Enclosure rating:
NEMA 4X (IP 66)
Mounting Orientation:
Mount in any position
Weight:
10 oz. (283 g)
Agency approval (CE):
EN 55022
EN 55024
EN 61000‐4‐2
EN 61000‐4‐3
EN 61000‐4‐4
EN 61000‐4‐5
EN 61000‐4‐6
