6 Software download
If we want to download the software to either the drive control or the func-
tion control it is possible with the SW download command. This can be
reached from the tools-menu. When this command is sent we reach the
Software download screen. Here we can chose which file to download to
the function control software (FEG SW) and which to download to the drive
control (ECO SW).
Table 1 Software file names
During the downloading of the software there is a feedback from the LEDs
on the motor.
Table 2 Feedback from the LED
Function motor Drive Motor
FEG SW Feg_R32C_release.mot Feg_R32C_release.mot
ECO SW A_STEP_A_7.mot A_PM_A_8.mot
Function motor LED colour Interval
1 Downloading FEG SW green/red fast flashing
2 Downloading FEG SW green fast flashing
3 Rebooting green slow flashing
4 Running green fixed
