Fill-Rite FR600G Series AC Transfer Pumps - Manual (Page 17)

17
Motor
Power -AC 115, 230, 115/230 115 VAC
HZ 50, 60, 50/60 60 HZ
Power - DC 12, 24, 12/24 N/A
HP (horsepower) rating 1/4 HP
Power cord length (feet) N/A
Power cord gauge (AWG) N/A
DC Power cord N/A
Amps (FLA) 1.5 A
RPM 2600
Duty cycle 30 min.
Thermal protection switch Yes
Circuit protection fuse None
Certification UL/cUL
Pump
Type- rotary, diaphragm, gear,
vane
Rotary Vane
GPM in supplied configuration Up to 14.8
GPM open flow - no hose or
nozzle
Up to 17.4
By-pass pressure rating (psi) -
Max
16 psi
Dry vac (in Hg) 5
Head- Max (Ft.) 37
Anti-siphon valve None
Inlet - Size / Thread 1” NPT
Outlet – Size / Thread 1” NPT
Mount 2” Bung (NPT)
Material -pump housing Cast Iron
Material- wetted material BUNA-N
Rotor material Powdered Iron
Rotor vane material Sintered Bronze
Compatible fluids
Diesel, gasoline, BioDiesel
up to B20, E15, Kerosene
Warranty 2 Years
Strainer Mesh Size 20 x 20
115 VAC
60 HZ
N/A
1/4 HP
N/A
N/A
N/A
1.5 A
2600
30 min.
Yes
None
UL/cUL
Rotary Vane
Up to 14.8
Up to 17.4
16 psi
5
37
None
1” NPT
1” NPT
2” Bung (NPT)
Cast Iron
BUNA-N
Powdered Iron
Sintered Bronze
Diesel, gasoline, BioDiesel
up to B20, E15, Kerosene
20 x 20
1 Years
Technical Information AC Pumps
FR600 SD600
FR600 SD600
