16
Motor
Power - AC 115, 230, 115/230 N/A
HZ 50, 60, 50/60 N/A
Power - DC 12, 24, 12/24 12
HP (horsepower) rating 1/4 HP
Power cord length (feet) 18'
Power cord gauge (AWG) 12 AWG
DC Power cord connectors NONE
Amps (FLA) 20
RPM 2600
Duty cycle 30 min.
Thermal protection switch Yes
Circuit protection fuse NONE
Certification
UL, cUL Motor, ATEX,
CE*, ANZEx
Pump
Type- rotary, diaphragm, gear,
vane
Rotary Vane
GPM in supplied configuration Up to 20
GPM open flow - no hose or nozzle 21
By-pass pressure rating (psi) - Max 16 psi
Dry vac (in Hg) 5
Head- Max (Ft.) 37
Anti-siphon valve None
Inlet - Size / Thread 1” NPT 1” BSPP*
Outlet – Size / Thread 1” NPT 1” BSPP*
Mount 2” Bung NPT 2” BSPP*
Material -pump housing Cast Iron
Material- wetted material BUNA-N
Rotor material Powdered Iron
Rotor vane material Sintered Bronze
Compatible fluids
Diesel, gasoline,
BioDiesel up to B20,
E15, Kerosene
Warranty 2 Years
Strainer Mesh Size 20 x 20
N/A
N/A
24
1/4 HP
18'
12 AWG
NONE
10
2600
30 min.
Yes
NONE
UL, cUL Motor, ATEX,
CE*, ANZEx
Rotary Vane
Up to 20
Up to 20
16 psi
5
37
None
1” NPT 1” BSPT*
1” NPT 1” BSPP*
2” Bung NPT 2” BSPT*
Cast Iron
BUNA-N
Powdered Iron
Sintered Bronze
Diesel, gasoline, BioDiesel
up to B20,
E15, Kerosene
20 x 20
2 Years
Technical Information DC pumps (G/GE models)
FR4200 Series FR4400 Series
FR4200 Series FR4400 Series
* CE certified models: see page 20
