Hardware installation – EXP Computer CRW-940 User Manual
Page 3
3
HARDWARE INSTALLATION
1. Connect the 36-pin connector to the drive. Press firmly until the
interface connector is seated.
2. Place the CD-RW drive in the horizontal position. The drive is designed
to operate only in the horizontal position. Operating the CD-RW drive
in any abnormal position is not recommended.
3. Connect the AC adapter plug into the DC IN Jack at the rear panel of the
CD-RW drive.
Note: Only use the AC adapter included with this USB CD-RW Station. Using
the incorrect AC adapter will result in permanent and unpredictable
damage to the CD-RW drive.
4. Attach the AC adapter to a working AC power outlet.
5. Continue with the Software Installation on the next page.
36-pin port connector of
the USB cable
Interface
connector
DC in Jack
