25
In the Advance interface, after clicking preset “Setting” button, a dialog box will
pop-up as below：
Pic 2-36 Preset point setting
In the preset set interface, click Setting button to see a window as below：
Pic 2-37 Preset setting
User can control the P.T.Z up, up left, down, right down, left , left down, right and up
right and stop rotating；can adjust the rotation speed of the PTZ, focus and aperture；choose
preset arrange NO.Click “Save” button to save the settings，click
icon to hide the tool
bar, right-key can remerge it；click icon to exit the current interface
In the preset interface, click ”OK” button to save the setting; click ”Exit” button to exit
current interface.
In the Advance interface, click cruise “Setting” button, a dialog box will pop-up as
below：
Pic 2-38 Advance - cruise “Setting”
Click Add button to add cruise line（max 32 cruise line can be added）；select a cruise
line and click Setup button, to see a window as below：
