- FLK : Select this when you experience picture flicker
- AUTO : Select this mode to control the shutter speed automatically.
Shutter speed is automatically controlled depending on the brightness of the screen.
▶ AGC : You can adjust it Low, Middle and High level.
The higher the gain level, the brighter the screen but the higher the noise.
▶ SENSE-UP : When it is night of dark, the camera automatically detects the light level and
maintains a clear pictur.
■ DC ■ VIDEO ■ MANUAL
■ SHUTTER ■ AGC ■ SENS-UP ■ BRIGHTNESS
■ ACCE ■ DEFOG ■ BACKLIGHT ▶ BRIGHTNESS : You can control the brightness by using the Left and Right button in Manual Lens mode.
■ ATW ■ AWC→SET ■ MANUAL ▶ ACCE : If there are bright area and dark area on the screen at the same time,
■ INDOOR ■ OUTDOOR this function makes both areas to be in clear image
■ COLOR ■ AUTO ■ EXT ■ B/W OFF, LOW, MIDDEL, HIGH 4step
■ 2DNR ■ 3DNR ■ SMART NR
■ CAM TITLE ■ D-EFFECT ■ MOTION ■ PRIVACY
■ LANGUAGE ■ DEFECT ■ RS485
OSD Manual
Function Menu
SPECIAL
DAY & NIGHT
NR
WHITE BAL
EXPOSURE
LENS
■ Function Menu Structure
2 1
This function Deactivates when the AGC "OFF", DAY&NIGHT "OFF"
OFF : Deactivates the Sense-up function.
AUTO : You can adjust brightness by increasing or decreasing the shutter speed
- 1.3M : x2 ~ x30, 2.1M : x2 ~ x60
* Note that the higher the zoom level, the brighter the screen, but the more likely it
is that an after-image will appear.
* Although Noise, Spots, and Whitish symptoms may occur in SENS-UP operation when the zoom
Notes
■ SHARPNESS ■ MONITOR ■ OSD ■ LSC
■ NTSC/PAL
RESET ■ FACTORY ▶ DEFOG : Carry out defog function
EXIT OFF, LOW, MIDDEL, HIGH 4Step
▶ BLC : This function allows you to get a clear pictures of objects even the objects
in strong backlight.
- BLC : Enables a user to directly select a desired area from a picture, and to view the area more clearly.
- GAIN : LOW, MIDDLE, HIGH
- AREA : Area Set(Size & Position)
LENS - DEFAULT : Factory reset
● Using this function, you can control screen brightness ▶ SENSE-UP : When it is night of dark, the camera automatically detects the light level and maintains a clear picture.
1. When the SETUP menu screen is displayed, select 'LENS' by using the Up and - SELECT : AREA1, AREA2, AREA3, AREA4
Down buttons so that the arrow indicates 'LENS'. - DISPLAY : SELECT AREA ON/OFF
▶ DC/VIDEO : Select Auto Iris Lens - LEVEL : Masking Level Set
▶ MANUAL : Select Manual Lens - MODE : DAY and NIGHT
EXPOSURE - BLACK MASK : Mask OFF
1. When the SETUP menu screen is displayed, select 'LENS' by using the Up and - DEFAULT : Factory reset
Down buttons so that the arrow indicates 'LENS'. ※ AREA Set
▶ SHUTTER : Auto / Manual - Use Narow Button to set
※ Out Door : Auto Size and Position
※ In door : NTSC : 1.3M→1/60 , 2.1M→1/30
PAL : 1.3M→1/50 , 2.1M→1/25
ADJUST
ACCE ON ACCE OFF
How to use the camera
⊙ An item with the , you can move to sub menu pressing SET button
⊙ An item with the - - -, icon is unavailable due to function settings.
Notes
