eLine Technology HDSDI-MD2-4 User Manual
Page 3
* DISPLAY : SELECT AREA ON/OFF
▶ MONITOR
Use Narow Button to set Size and Position
* CRT : CRT Monitor
* LCD : LCD Monitor
- Set : GAMMA, BLACK LEVEL, BLUE GAIN, RED GAIN
▶ OSD
* TEXT COLOR : OSD Font & Color adjustable
8 step of Color
* Sensitivity : When sensitivity number is high, motion detection sensitivity is increased to recognize
* OUTLINE : OSD Out Line
even small movement
▶ LSC : Lens shading compensation
* DEFAULT : Factory Reset
▶ NTSC/PAL : Select NTSC / PAL
RESET
▶ PRIVACY : Hide an area you want to hide on the screen.
1. When the SETUP menu screen is displayed, select RESET by using Up and
* SELECT : AREA1~8
Down buttons so that arrow indicates RESET.
* DISPLAY : SELECT AREA ON/OFF, SET Size and Position
2. Select a mode by using Up and Down buttons.
* COLOR : 0 ~ 15 Color Step
▶ FACTORY : Resets the camera settings to the factory defaults.
* DEFAULT : Factory Reset
Language and Communication status is not initialized
▶ Language : You can select the menu language according to your requirement.
EXIT
- It can be changes 5sec. later.
Press the SET button in the Exit menu to save the current settings and exit the Main SETUP menu.
- Supplied Language : English
5
6
▶ Defect CMOS correction to compensate for defects that can occur at the low light conditions.
* LIVE DPC : Auto Defect
* LEVEL : Level of Auto Defect
* STATIC DPC : Manual Defect
* START : Start Defect
(Close the lens to shield the light, Select the START and press the SET button twice)
* LEVEL : Manual Defect Value
* SENS-UP : Defect Sens up Value
▶ RS485 : This function sets up the camera communication status when controlling the camera through an
external device.
* You can control SETUP Menu through this port by using external controllers like a remote
controller that RS-485 Communication is supported
▶ VERSION : Ver. of Camera
ADJUST
1. When the SETUP menu screen is displayed, select ADJUST by using Up and
Down buttons so that arrow indicates ADJUST.
2. Select a mode by using Up and Down buttons.
▶ Sharpness : As you increase this value, the picture outline becomes stronger and clearer
Adjust this value appropriately depending on the sharpness of the picture.
* RESOLUTION : RESOLUTION ON/OFF
MEMO
