5
Right view
7 Microphone-in jack Accepts a mono/stereo condenser
microphone.
8 Volume control Controls the volume of the speakers.
9 Video capture kit slot Accepts the video capture kit option
on the left side of the computer.
# Item Description
1 Video capture kit slot Accepts the video capture kit option on the
right side of the computer.
2 Battery bay Houses the computer's battery pack.
3 AcerMedia drive Houses removable media drive modules.
4 LED indicator Lights up when the AcerMedia drive is active.
5 Eject button Ejects the compact disc from the drive.
6 Emergency eject slot Ejects the compact disc when the computer is
turned off. See page 46 for more details.
7 Power jack Connects to an AC adapter.
# Item Description
