SECTION 2
SPECIFICATIONS
MODEL PFP-600 TRANSMITTER/INDICATOR/TOTALIZER
Flow Accuracy............................
+\-2.0% (Application Dependent) at 70
° F (25° C)
Level Accuracy..........................
Better than +\- 1.% (Application Dependent) at 70
° F (25° F)
Linearity...................................... Better than +\-0.5% under flow.
Repeatability............................... Better than +\-0.5% under flow.
Rangeability................................ 10:1 or greater.
Standard Scale........................... Gallons per Minute (as specified). Other engineering
units, optional.
Display......................................... LCD-BACKLIT, dual line, 20 Characters, 0.23” high.
Resolution................................... 0.01 Engineering unit.
Standard Output.......................... 4-20 mA dc into 1000 ohms max. isolated.
Totalizer...................................... Resettable, first line of LCD display, With multiplier.
Service........................................ Partially filled pipe flow in engineering units.
Wall or pipe stand mounting. General purpose areas only.
Enclosure.................................... Fiberglass, NEMA 4X, Water resistant.
Power.......................................... 115 VAC +/-10%, 50/60Hz.
Ambient Temperature Range...... 32
° F. (0° C) to 122 . (50° C) Optional enclosure heater
available for extended low temperature operation.
Operation Liquids......................... Liquids containing 25 PPM 30 micron or larger suspended
solids, up to 1.0% suspended solids.
Minimum Velocity Sensing..........
0.2 FPS
Minimum Level Sensing..............
2.6”
