PFP
µP FUNCTIONS
To set engineering units press “UNITS” key. The
µP display will show “UNITS”. Use
the “SCROLL” keys to increase or decrease value. The default value is 1. When
finished, press “ENTER” key to exit.
NOTE: after units has been changed, all other levels for FULL-SCALE, ID, ALARMS, must be re-
entered.
0 = FPS 6 = CMH
1 = GPM 7 = LPM
2 = GPH 8 = MLD
3 = MGD 9 = LEVEL INCHES
4 = CFM 10 = LEVEL CENTIMETERS
5 = MPS
To set 4-20 mA full-scale, press “FULL-SCALE” key. The
µP display will show “FULL-
SCALE”. Use the “SCROLL” keys to increase or decrease value. The default value is
10.00 . When finished, press “ENTER” key to exit.
units = 1-4 GPM
full-scale range is 1.00 - 20.00 FPS F.S (FPS) = ID
∗ ID∗ 2.45
units =5-8
LPM
full-scale range is 0.304 - 6.08 MPS F.S (MPS) = ID
∗ID∗ .047
units =9
full-scale range is 4.00” - 60.00”
units = 10
full-scale range is 10.2 cm. - 152.00 cm.
To set pipe ID, press “I.D.” key. The
µP display will show “ID (IN)” or “ID(MM)”. Use the
“SCROLL” keys to increase or decrease value. The default value is 10.00. When
finished, press “ENTER” key to exit.
units = 1-4, and 9
pipe ID range is 4.00” - 60.00”
10
