Parameter setting items list:
Setting items
Parameter setting sheet
Burst Continuous
No
Format
Modulation
✓
✓
✓
Frame
✓ ✓
—
Slot
✓
✓
—
Field
✓
✓
—
Data
—
—
✓
Filter
✓
✓
✓
Pattern Name
✓
✓
✓
•
Parameter setting items list:
Items
Display
Outline
Setting range
Modulation Type
Modulation system
PI/4DQPSK, BPSK, QPSK, 8PSK, 16QAM,
Modulation
16QAM (ARIB_STD_T86), 64QAM, 256QAM
Symbol Rate
Symbol rate
1ksps to 40Msps (Specified in increments of 1 sps.)
The Number of Frames
Frame number
1 to 4088
Frame
The Number of Slots
Slot numbers in one frame
1 to 10
per Frame
1, 24field
Guard field
Set the number of bits listed in the separate table
according to “Modulation Type.”
2, 23field
Ramp field
Set the number of bits listed in the separate table
Slot(Burst)
according to “Modulation Type.”
3 to 22field
Fixed (Fixed data) field
Set an integer from 0 to 32.
3 to 22field
DATA (PN9, PN15) field
Set an integer from 0 to 400.
4 to 22field
CRC(Cyclic Redundancy
Check character) field
Set an integer from 0 to 32.
1 to 24field
Fixed (Fixed data) field
Set an integer from 0 to 32.
Slot(Continuous)
1 to 24field
DATA (PN9, PN15) field
Set an integer from 0 to 400.
2 to 24field
CRC(Cyclic Redundancy
Check character) field
Set an integer from 0 to 32.
Fixed
Sets a hexadecimal fixed
data.
0 to the maximum value of the number of bits being set
Field
CRC
Sets the CRC calculation
1 to the number of bits in the field on the left to CRC
(Burst/Continuous)
field by an integer.
(except Guard and Ramp fields)
Data Field
Selects a continuous pattern.
PN9, PN15, 16-bit Pattern, ALL0, ALL1
Enter arbitrary hexadecimal number for “16-bit Pattern.”
Data(No Format)
Data
Selects a continuous pattern.
PN9, PN15, 16-bit Pattern, ALL0, ALL1
Filter
Filter type
Root Nyquist, Nyquist
Filter
Roll Off
Filter roll-off rate
0 to 1.00 (up to the second digit of fraction)
RMS
RMS value of waveform
pattern data
651 to 4104
Pattern Name
Pattern Name
Waveform pattern file name
Within 20 characters
Comment
Comment
Within 38 characters
Calculation
Starts waveform pattern data generation after setting parameters.
Optional
MX370102A TDMA IQproducer
•
Parameter setting items list:
