Optional
•
ARIB STD-T79
Sampling Rate
128 kHz
Symbol Rate
16 kHz
•
ARIB STD-T86
Sampling Rate
90 kHz
Symbol Rate
11.25 kHz
■
Frame configuration
•
RCR STD-39, ARIB STD-T79 frame configuration
The uplink frame (TDMA) and downlink frame (TDM) both
generate data in frame cycles of 4-slot length (40 ms) defined
as a basic frame length. The PN9 pseudo random pattern of
the traffic channel (hereinafter called TCH) in a slot is
independent per slot and has continuity.
Waveform pattern
Uplink / Downlink
Transmit frame
UpLink
Uplink
/ Downlink
0, x, x, x
DownLink 1
Uplink /
Downlink
0, x, x, x
DownLink 4
Uplink /
Downlink
0, 1, 2, 3
Direct
Uplink / Downlink
1, x, x, x
PN9 —
—
PN15
—
—
Waveform pattern
Uplink / Downlink
Transmit frame
Down_tch
Uplink
/ Downlink
0, 1, 2, x, 4, 5
Down_tch_all
Uplink /
Downlink
0, 1, 2, x, 4, 5
Down_cch
Uplink /
Downlink
x, x, x, 3, x, x
Up_tch
Uplink
/ Downlink
x, x, x, 3, x, x
Up_cch
Uplink
/ Downlink
x, x, x, 3, x, x
PN9 —
—
PN15
—
—
MX370002A Public radio system waveform pattern
40 ms
PN9 is continuous in the same slot.
Slot 0
Slot 1
Slot 2
Slot 3
Slot 0
Slot 1
Slot 2
Slot 3
•
ARIB STD-T61 frame configuration
The uplink/downlink frames both generate data in cycles of 40
ms defined as a basic frame length. The PN9 pseudo random
pattern of TCH in a frame has continuity in each frame.
•
ARIB STD-T86 frame configuration
One frame consists of 6 slots and the data is generated in this
frame cycle. The PN9 pseudo random pattern of TCH in a slot
has continuity in all slots.
PN9 is continuous in each frame.
40 ms
Frame
0
Frame
1
1 Frame 80 ms
Slot
0
off
Slot 1
off
Slot 2
off
Slot 5
off
UpLink CCH
Slot 4
off
Slot 3
CCH
1 Frame 80 ms
Slot 0
off
Slot 1
off
Slot 2
off
Slot 5
off
UpLink TCH
Slot 4
off
Slot 3
TCH
Slot 3
off
1 Frame 80 ms
Slot 0
CCH
Slot 1
off
Slot 2
off
Slot 5
off
DownLink
CCH
Slot 4
off
Slot 3
off
1 Frame 80 ms
Slot 0
CCH
Slot 1
TCH
Slot 2
TCH
Slot 5
off
DownLink
TCH
Slot 4
off
Slot 3
TCH
1 Frame 80 ms
Slot 0
TCH
Slot 1
TCH
Slot 2
TCH
Slot 5
TCH
DownLink TCH
(all
Slot
)
Slot 4
TCH
