PrintPAD CN70/70e USER'S GUIDE
Using a CardReader
General Guidelines
To wake up the CardReader, insert a card into the CardReader slot. One short beep indicates the CardReader/
printer is awake.
If you are using a Magnetic CardReader, insert a card with the stripe facing away from the printer. The card
can be swiped in either direction.
For information on CardReader LED indicators and audio indicators, see
CardReader Indicators on page 8.
CardReader Indicators
Audio Indicators
Using External Charging
Overview
External charge-capable printers have two charging contact points located on the back of the printer's case (Figure
17).
Note: The following information applies to printers with the CardReader option.
Beep
Description
Action
1 long
Bad read.
Swipt card again.
2 short
Good read.
None.
Note:
T
he following information applies to printers installed with external charge capabilities.
Figure 16
Figure 17
(2) Charging contact points
